Products | Active Components | SFP28 Transceivers
25G SFP28 DWDM
Nexconec 25G SFP28 DWDM Transceivers?are hot-pluggable, and Duplex LC receptacle optical interface compliant for 25 Gigabit Ethernet and Infiniband EDR Applications.
FEATURES AND APPLICATIONS
- Up to 25.78Gbps Data Links
- C-band cooled EML laser
- Single +3.3V power supply
- Hot-pluggable
- Compliant with SFP28 MSA with LC connector
- RoHS Compliant
- Power dissipation<2.3W
- 2-wire interface with integrated Digital Diagnostic monitoring
- Distance up to 10km on 9/125um SMF
- Case operating temperature range
- Commercial: -5°C to +70°C
- Industrial: -40°C to +85°C
- 25G Ethernet,CPRI Option 10
| Part Number | Package | Data Rate | Wavelength | Reach | TX | RX | Connector | TX Power | RX Sensitivity |
|---|---|---|---|---|---|---|---|---|---|
| NX-SP-Q2G25-10-xx | SFP28 | 25G | DWDM | 10km | EML | PIN | LC | -0~5dBm | -13.5dBm |
| Part Number | Product Description |
|---|---|
| NX-SP-Q2G25-10-xx | SFP28 DWDM Transceiver LC Duplex 10km |
1. Where (10 = 10km) denotes reach in kilometers.
2. Where "xx" denotes compatibility short codes. (xx = CI for Cisco, xx = JP for Juniper etc.)
3. Find Compatible Short codes in datasheet at Order Information area.
