3U FIBER OPTICAL ROTARY PATCH PANEL - SW01-144SCA-xx

SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx
SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx SW01-144SCA-xx

Rotary Swing out 3U patch panels are designed for the FTTH networks, specifically for the street cabinet where full front access is required. This 3U panel accommodates 144 SC/APC adapters and is loaded with bend insensitive pigtails G657A2 and the complete splicing trays and rooting.

FEATURES AND APPLICATIONS
  • Holds up to 144 SC Simplex footprint adapters
  • Designed for 19'' and ETSI 21’’ frames
  • Right and left opening
  • Supplied fully loaded ready to splice
  • Datacenter storage area & Central office, POP
  • Fiber to the home (FTTH) Street cabinets
  • LAN/WAN

Product Information

pdfDATASHEET.pdf View Download
Mounting Type 19” and compatible ETSI 21”
Opening Type 3 Individual Right or Left Hinge swing out trays
Dimension 132 x 482 x 265mm
Material Anticorrosive Steel and FR polymer
Housing Color Painted light grey RAL7035
Operating Temperature －25℃～＋55℃(5 to 95% RH)
Net Weight 7.5kg
Slot Type SC/APC Simplex adapters
Number of Slots 144
Fiber Type Singlemode Bend Insensitive G657A2 Easystrip
Insertion Loss IL ≤ 0,20dB / RL 65dB
Part Number Product Description
SW01-144SCA-LF 3U Pivot Panel 144FO SCA loaded Pigtails SC/APC OS2 G657A2 LSZH Easystrip, Opening Left
SW01-144SCA-RI 3U Pivot Panel 144FO SCA loaded Pigtails SC/APC OS2 G657A2 LSZH Easystrip, Opening Right
