1U 16 Ports UTP/STP Unloaded Patch Panel - CMX1SUN-16
NEXCONEC 1U 16 ports unloaded shielded keystone patch panel allows flexibility for the users during installations. It gives you the benefits of only using ports required by installing the desired number of jacks into the frame.
With the port identification number, which help the end user to recognize the ports while/after installation. When mounted with NEXCONEC unshielded or shielded keystone jacks for Cat 5E, Cat 6 and Cat 6A, your completed panel will conform to ANSI/TIA/EIA 568A B.2.2001, ISO/IEC11801:2002 and EN50173 2 standards.
FEATURES AND APPLICATIONS
- Compatible with all NEXCONEC UTP & STP keystone jacks
- 19’’ rack mountable
- Support up to 16port in 1U height
- Supplied with rear cable managers and fixings
- Connection between wall outlets or equipment’s
- Compatible with all categories of shielded keystone jacks
| Parameters | Value |
|---|---|
| U Size | 1U (44.4mm) |
| Depth | 151.5mm |
| Frame Material | Cold-rolled steel |
| Material Thickness | 1.6mm |
| Operating Temperature | -10°C / +60°C |
| Compliance | ANSI/TIA-568-C.2, ISO 11801, IEC 60603-7 |
| RoHS | Compliant |
| Warranty | 12 Months |
| Width | 482mm |
| Net Weight | 0.9KG |
| Packed Weight | 1.1KG |
| Color | Black, RAL 9004 |
| Part Number | Product Description |
|---|---|
| CMX1SUN-16 | NEXCONEC 1U 16port STP/UTP KJ Patch Panel Unloaded |
